Feature
Physical Properties：
| Property | Unit | Standard | FUP-50C | FNU-50C | FUS-50C |
| Type | - | - | Ether | Ether | Bio-ester>40% |
|---|---|---|---|---|---|
| Density | g/cm3 | ASTM D297 | 0.18~0.2 | 0.16~0.18 | 0.18~0.2 |
| Hardness | Shore C | ASTM D2240 | 47~53 | 48~52 | 50~54 |
| Tensile strength (without skin) | kgf/cm2 | ASTM D412 | 14~16 | 7~9 | 17~19 |
| Elongation (without skin) | kgf/cm2 | ASTM D412 | 350~400 | 140~190 | 280~350 |
| Tearing test (without skin) | kgf/cm2 | ASTM D624 | 8~9 | 5~7 | 10~13 |
| Resilience | kgf/cm | ASTM D2632 | 42~46 | 54~60 | 32~36 |
| Compression set | % | CNS3560 K6351 | 8~16 | 8~16 | 40~48 |
| UV grade | grade | ASTM G154 | 4 | 5 | 4 |
| Ross Flex (23°C) | Times | SATRA TM92 | >125,000 | - | - |
| Heat agent(60°C) | grade | JIS K7373 | 4 | - | - |
* All testing refer to standard environment with 23℃±2℃, RH 50%.
Storage：
Please store in a cool and dry setting and keep it out with sunlight. The storage life is a year only, please check the quality and durability if it is expired.
Note：
Please inspect the compatibility before any manufacturing process since it may affect physical property, reliability and durability. For more technical issues, please contact Shuang-Bang Industrial.
